- Transposer : +/- 24. Octave : +/- 2. Poliphony: 128 note. Multitimbral 48 parts.
- DISPLAY Lcd color Tft 7”. Touch sensitive 800 x 480 dots. Brightness control.
- PLAYER Double Player. Files recognized : Wav, Midi , Mp3, Mp4, Avi, Mov, Flv, Cdg, Jpg, Txt, Pdf.
- PLAYER FUNCTIONS Marker. Sync/Next. Autoplay. Lead Mute. GM part. Lyric Off. Cross fade. File Search. Play List. My Folder.
- Transposer. Time stretching. Metronome Click. Midi Multimix. Song Drum Restyle.
- Audio and Midi synchronize. Audio Multitrack Player: 5+1 Audio tracks with separate slider control.
- DJ Double Audio and Midi player with Tempo & Pitch stretching, Pfl, Sync, Tap tempo, Cue, Fx Pad,
- Backspin, Brake.
- JUKE BOX Play List, My Folders, SFX Special Effects.
- PIC & MOVIE Jpg & Mp4, Avi, Mov, Flv, Karaoke background, Movie/PDF To RGB, Pic List, Autoshow.
- DVI Video Monitor Out, Karaoke Lyric / Mirror.
- MENU Disk, Midi , Play Modes, Audio Edit, Language, Footswitch, Preferences, Controls, Video, Reg.
- Set up, Arabic Mode. Instruction Manual: Html on board.
- MEDIA Internal Storage: SSD Card 16G. External Storage: Removable SATA 2/3 2.5 HD. USB: 3 Host + 1 device.
- SOUNDBOARD 543 GM Sounds. 4 Sound Banks. Voice List. 48 Drum Sets + Stereo Special Kit. Live Drum Modeling.
- VOICES 368 Preset Voices. New Stereo Grand Piano. 368 User Voice. 2nd Voice. V-Tone.
- Double Up / Down. Harmony. EFX Insert. Voice Editing.
- RAM SOUNDS 46 voices (instant loading). Hi-quality tonewheel Organ and Orchestral sounds.
- ARRANGER 260 Styles full Audio Drum and Groove equipped. User Style section. Midi Drum Mixer & Remap.
- 4 Arranger ABCD. 4 Fill. 4 Break. 3 Intro. 3 Ending. Drum, Groove, Bass, Chords 1-5. Lower 1-2. Auto Fill.
- Fill to Arrange. To End. Reintro. Key Start. Key Stop. Restart. Count In. Drum Boost. 4 Voice Set.
- Voice to ABCD. Voice & Vari. 5 User Tabs. V-Tone.
- ARRANGER MODES Pianist (Auto- Standard). Bassist (Easy_Expert). Manual Bass. Bass to Lowest.
- STYLE MODELING Interactive Modeling Library with massive Audio Drums, Bass, Latin Groove, Piano,
- Guitar and Orchestral templates.
- PLAY MODES Master keyboard. Accordion Style & Classic. Organ with Pedalboard.
- Guitar mode with Efx (thru Input).
- REGISTRATIONS 4 Bank x 1024 Regs. Full Panel and function programming.
- DSP Type: Chorus, Reverb, Flanger, Phaser, Tremolo, Rotary, Echo Delay, Tap Delay, Equalizer, Distorsion,
- Amp simulator, Compressor, Filter. EFX Insert (54 types). 10 programmable Insert Chains.
- LIVE FX CONTROL Decay, Release, Filter and Resonance slider control applied to Player, Drum, Bass & Chords.
- Low_Hi Eq to Player.
- RECORDING HD Recording : 1 Stereo track. Loop. Audio Edit with Cut, Normalize. Midi Recording. Phrase and Song.
- MICRO & VOICETRON XLR Input. Gain control. Volume. Reverb. Micro On/Off Edit. Talk. 3 Voice Vocalizer.
- 10 Voicetron Presets + 10 User.
- MIDI In1 (Gm), In 2 (Keyb). Out. Thru. Midi Set up: Standard, Computer & Sequencer, Keyboard Right,
- Accordion, Player , Style.
- OUT Left/Right Stereo, Pedal Volume, Sustain Pedal, Micro Out.
- INPUT Guitar (Instrument) / Micro2.
- HEADPHONE Stereo Headphone. Aux separate Out Assign (to Drums, Right, Bass, Click).
- OPTIONAL Footswitch 6 or 13, Volume Pedal, Sustain pedal, Bag.
- AMPLIFIER & SUPPLY 2 x 20 watts. 2 x Midrange speakers + 2 x Tweeters. Speaker On /Off. Power supply: External 15 V.
